Superstructure turning speed | 9 1/min |
Travel speed | 3.2 mph / 5.2 km/h |
Break Out Force Bucket | 11,397.8 lbf / 50.7 kN |
Break Out Force Lift Arm | 6,924.1 lbf / 30.8 kN |
Length | 241.6" / 6,137 mm |
Operating weight (min.-max.) | 13,399.7 - 16,221.6 lb / 6,078 - 7,358 kg |
Digging depth (max.) | 164.7" / 4,184 mm |
Width | 76.8" / 1,950 mm |
Height | 97.6" / 2,478 mm |
Cylinder | 4 |
Cylinder capacity | 135.2 cu in / 2,216 cc |
Effective power | 56.3 hp / 42 kW |
Nominal Engine speed | 2,000 1/min |
Battery capacity (nom. value) | 100 Ah |
Engine type | Turbodieselengine |
Exhaust-gas limit | EU Stage V |
Manufacturer | Perkins |
Engine designation | 404J - E22T |
Operating pressure | 3,480 psi / 240 bar |
Flow rate | 38 gal/mi / 144 l/min |
Flow rate max. | 38 gal/mi / 144 l/min |
Tank capacity | 24.3 gal US / 92 l |
Operating pressure slewing gear | 215 bar |
Hydraulikpump | Variable displacement and gear pump |
Operating pressure | 3,480 psi / 240 bar |
Shipping weight | 12,800 lb / 5,806 kg |
Height with cab | 97.6 inches / 2478 mm |
Height of dozer blade | 16.7 inches / 423 mm |
Total height with rotating beacon | 104.5 inches / 2654 mm |
Width of upper carriage | 74.9 inches / 1902 mm |
Width of cab | 39.4 inches / 1000 mm |
Width travel gear | 76.8 inches / 1950 mm |
Width of dozer blade | 76.8 inches / 1950 mm |
Transport length short shovel arm | 238.8 inches / 6065 mm |
Transport length long shovel arm | 243.9 inches / 6194 mm |
Digging depth max., short shovel arm | 153.3 inches / 3893 mm |
Digging depth max., long shovel arm | 165.1 inches / 4193 mm |
Piercing depth max., short shovel arm | 108.8 inches / 2764 mm |
Piercing depth max., long shovel arm | 119.5 inches / 3036 mm |
Piercing height max., short shovel arm | 257.4 inches / 6537 mm |
Piercing height max., long shovel arm | 266.5 inches / 6770 mm |
Dumping height max., short shovel arm | 183.6 inches / 4664 mm |
Dumping height max., long shovel arm | 192.8 inches / 4898 mm |
Digging radius max., short shovel arm | 259.4 inches / 6590 mm |
Digging radius max., long shovel arm | 270.7 inches / 6877 mm |
Max. reach at ground level (short shovel arm) | 254.9 inches / 6475 mm |
Max. reach at ground level (long shovel arm) | 266.6 inches / 6772 mm |
Tail swing radius | 53.7 inches / 1363 mm |
Tail swing radius with tail weight | 58.3 inches / 1481 mm |
Boom offset max. (to center of bucket right side) | 30.2 inches / 766 mm |
Boom offset max. (to center of bucket left side) | 19.4 inches / 492 mm |
Stacking height max. (dozer blade above surface) | 15.9 inches / 403 mm |
Digging depth max. (dozer blade below surface) | 16.8 inches / 427 mm |
Length travel drive | 99.1 inches / 2516 mm |
Max. swivel angle (arm system to the left) | 65 ° |
Max. swivel angle (arm system to the right) | 57 ° |
Track width | 15.7 inches / 400 mm |
Boom swing radius center | 64.1 inches / 3159 mm |
Boom swing radius right | 59.8 inches / 3097 mm |
Boom swing radius left | 54.0 inches / 2732 mm |
